Keychron Q1 Max QMK/VIA Wireless Custom Mechanical Keyboard

SKU: Q1M-M1
R$ 1.169,00

Type
Color
Switch

The Fully Assembled version includes:
  • The keyboard PCB, the case, and the PC plate.
  • Keycaps (included Mac & Windows keycaps).
  • Switches.

The Barebone version does not include the keycaps and switches.

No discount codes can be used for the Q1 Max.

q1-max-3__PID:f9daf39a-d2ae-4e4c-8a92-974ae6e4d7ec

Keychron Q1 Max

Meet the Keychron Q1 Max, a full metal QMK/VIA wireless custom mechanical keyboard upgraded with a 2.4 GHz wireless connection, featuring a 1000 Hz polling rate. Elevating the typing experience further, it has been thoughtfully upgraded with multiple layers of acoustic foams, ensuring a premium sound quality with every keystroke.

q1-max-2__PID:eba0098f-0e10-402c-b2e5-d37087040a8e

Paired with many other premium features, such as the double-gasket design, PBT keycaps, screw-in stabilizers, and more, the Keychron Q1 Max promises an unparalleled typing journey that transcends expectations.

q5-max-3__PID:ed74b079-e28d-4264-a05e-18b4bb20bcaf
q1-max-features-icon__PID:7bf3ff79-d3aa-40f4-a3ff-afd1757ca3f9

Choose the keycaps, switches and more accessories for your Q1 Max

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the Q1 Max via Bluetooth 5.1 to three devices.

q1-max-4__PID:f6c22c64-f826-4e63-9002-48f14bc6720b

A Refined Piece Of Metal Art

The entire metal body is crafted with 6063 aluminum that is processed through CNC machined, polished, anodized, sandblasted, and undergoes 24 more manufacturing stages to make this solid metal piece of art that is the Q1 Max.

q1-max-6__PID:2d10e992-b66f-4c70-9a7b-3b5105243be7

Significantly Enhanced Acoustic Foams

Elevate the typing experience with a combination of premium acoustic foams such as IXPE, PET, and Latex. Each keystroke becomes enjoyable, making every tap a delight for the senses.

Easy Assemble

We designed every component to be able to assemble easily so you can customize and adjust each component with ease to create your ultimate typing experience.

q5-max-structure__PID:552e1621-4c8c-477e-bbf5-ceb688b2616d
q1-max-9__PID:3b510524-3be7-4624-a4be-569daa34829b

An Epic Core Inside The Keyboard

A powerful ARM Cortex-M4 chip (MCU) equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box on 2.4 GHz and wired modes (90 Hz on Bluetooth mode), which makes the latency hardly noticeable even in competitive games.

Double-Gasket Design

The Double Gasket Design is a new innovative structure in the industry. In addition to the gaskets on the plates, we added silicone pads between the top and bottom cases to significantly reduce the acoustic resonance between the metals and reduce the noise of the impacted metals.

Keychron Q1 75% Custom Mechanical Keyboard
q1-max-5__PID:efb2cab2-696b-423d-871d-9442f342657b

Experience the next level of key sounds and comfort with our gasket mount design together with a flexible PC (Polycarbonate) plate. This design combination allows the keyboard to maintain the flexibility of the gasket structure and improves the overall typing sound.

KSA Double-Shot PBT Keycaps

To further fine-tune your typing experience, we designed our unique Keychron spherical-angle (KSA profile) double-shot keycap set with premium non-backlight shine through PBT material, that is oil-resistant and durable for long-term use.

q1-max-1__PID:657bf07f-539e-412f-8787-f2ed72cab098

Suitable for All Devices

Built with the Mac users’ experience in mind while still retaining compatibility for Windows devices, the Q1 Max comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

q5-max-windows-keycaps__PID:7c9de201-b5da-447d-aa07-565668684207
q1-max-8__PID:f767bf4e-de7e-4b7d-b35b-3a06899ece69
pf-c4bbc56a--25358678__PID:e25843f1-e5a4-4544-9317-b515ec32c460
launcher__PID:43f1e5a4-3544-4317-b515-ec32c460a9cd

Program with QMK & Launcher.

The open-source QMK firmware means endless possibilities for key remapping, macros, shortcuts, and more. Now you can easily customize each key with the Keychron Launcher web app.

program-the-k14-pro-keyboard-with-launcher__PID:a4354413-17b5-45ec-b2c4-60a9cd720db4
Click here to use Keychron Launcher

* Please use the latest version of Chrome / Opera / Edge browser to open the Launcher and connect the keyboard to your device via wired mode.

q1-max-hot-swappable__PID:308ce014-2a30-469a-9302-d983c37b330b

Hot-swappable.

Every detail matters for a personalized typing experience, that’s why we give you the power. You can hot-swap every switch on the Q1 Max with almost all of the 3pin and 5pin MX style mechanical switches on the market (including Cherry, Gateron, Kailh, Panda, etc.) without soldering required. You can customize your own typing experience in seconds.

South-facing RGB

Comes with 22 types of RGB backlight settings. You can further fine-tune the RGB hue, saturation, brightness, effect speed, and different modes, or even remap these keys with QMK/VIA.

Gateron Jupiter Switch

Our exclusive Gateron Jupiter mechanical switch (for the Fully Assembled version only) comes with a 3-pin design, its pre-lubed with a reliable Gateron quality standard with up to 80 million keystrokes lifespan. While their unique LED diffuser design offers high RGB backlight transmittance and softer backlight effect. The banana switch provides an early tactile bump at the top with a uniquely smooth experience like those Panda switches on the market.

keychron-gateron-jupiter-mx-mechanical-switch-red-brown-banana__PID:e1f8abd8-9bb3-40ec-b4b1-4d96a72038a4
PCB Stabilizers

PCB Stabilizers

No detail is too insignificant when it comes to your fingertip feel. We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as the space bar, shift, enter, and delete keys. You can even customize your favorite stabilizers on your own.

Looking for ISO Layout?

The Q3 Pro ISO collection comes with fully assembled keyboards with 🇬🇧UK, 🇩🇪German, 🇩🇰🇫🇮🇳🇴🇸🇪Nordic, 🇨🇭Swiss, 🇫🇷French, and 🇪🇸 Spanish layout, and the “Barebone ISO Knob" option is suitable for all ISO countries (e.g.: 🇮🇹Italy, 🇵🇹Portuguese, 🇭🇺Hungary, etc.) to build their keyboard with keycaps in their preferred languages and switches.

Keychron Q1 Pro 75% Layout Wireless Custom Mechanical Keyboard ISO Layout

What's in the box?

q1-max-package-list_5d4d7db3-30e7-491c-8a73-c7fe4a21687c__PID:d032e617-89f6-452d-a93e-81a69d6e0630
q1-max-package-list-barebone_b4e9334d-d36c-4e5e-a2fb-41f846d04169__PID:5f0fe804-15e7-49e5-8352-0c37a355b6dc

Specs

Width145 mm
Length327.5 mm
Front Height22.6 mm (without keycaps)
Back Height 35.8 mm (without keycaps)
Feet Height2.4 mm
Angle5.2°
Weight1724 g ± 10 g (Fully Assembled version)
Body MaterialAluminum
Plate MaterialPC
SwitchGateron Jupiter (Fully Assembled version)
StabilizerScrew-in PCB stabilizer
BacklightSouth-facing RGB LED
Hot-swappableYes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
MCU ARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Polling Rate1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth)
N-Key Rollover (NKRO)Yes for both wireless and wired modes
KeycapKSA double-shot PBT keycaps, not shine-through (Fully Assembled version)
Battery4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off)Up to 180 hours (Lab test result may vary by actual use)
Wireless Working Time (RGB)Up to 100 hours (Lowest brightness)
Bluetooth Version5.1
Compatible SystemmacOS/Windows/Linux
ConnectivityBluetooth / Type-C wired
Bluetooth Device NameKeychron Q1 Max
Operating Environment-10 to 50℃
Keychron Q1 Max User Guide

Learn more about the Keychron Q1 Max such as the shortcuts, assembling guide, factory reset, and more in the FAQ section.
